Samsung is taking a step forward in mobile photography and videography with the launch of the Samsung 50MP ISOCELL GNK sensor, the promising successor to the popular 50MP ISOCELL GN1. This updated sensor greatly improves the picture.

Although the GNK sensor has similar dimensions and pixel measurements as the GN1, it stands out due to the integration of smart technologies. In particular, the sensor has a Dual Pixel Pro autofocus feature that provides fast focusing and clear images even when shooting moving objects.

One of the highlights of the Samsung 50MP ISOCELL GNK sensor is its extended dynamic range, which can reach up to 120dB. This function allows you to capture a wide range of details under different lighting conditions. Additionally, in pro mode the GNK sensor can shoot 14-bit RAW images, giving photographers greater creative control and precision.

For video enthusiasts, the GNK sensor supports 8K video recording at 30 frames per second without sacrificing field of view. It also meets a variety of video recording needs by offering HDR video capabilities and the flexibility to shoot FHD at 240 fps.

Brief specifications of Samsung ISOCELL GNK camera sensor:

• Effective resolution: 8160×6144 (50MP)
• Pixel size: 1.2 micron
• Optical format: 1/1.3 inch
• Color filter: dual tetrapixel Bayer RGB pattern
• Normal frame rate:
  • Up to 24fps at full 50MP
  • 90 frames per second at 12.5 MP
• Video frame rate:
  • 30fps at 8K
  • 120fps@4K
  • 240fps@FHD
• Louver type: electronic shutters
• ADC accuracy: 10 bits
• Supply voltage:
  • 2.2V for analog
  • 1.8V for I/O
  • 0.9 V to power the digital core
• Operating temperature: -20°C to +85°C
• Interface:
  • 4 lanes (2.5 Gbps per lane) D-PHY
  • 3 lanes (4.0 Gsps per lane) C-PHY
• Colour: RGB
• Autofocus: Dual Pixel Pro (PDAF)
• HDR: checkered HDR, Smart-ISO Pro
• Output formats: RAW8/10/12/14
• Analogue gain: x144@12.5MP and x72@50MP
